Learn more about the 3D Systems ProX 200
Production grade 3D printer capable of fabricating metal, metal alloy, and ceramic components
The ProX DMP 200 is a high-performance, high-quality 3D printing alternative to traditional manufacturing processes, offering reduced waste, greater speeds for production, short set up times, very dense metal parts, and the ability to produce very complex assemblies as a single part.
Features
- Uses Direct Metal Printing (DMP) technology
- Very dense, non-porous parts
- Typical accuracy is +/- 50 μm (+/- 0.002 in) on small parts, +/- 0.2% on large parts
- Repeatability of approximately 20 μm (0.0008 inches)
- Surface finish quality of up to 5 Ra μm (200 Ra micro inches)
- 3DXpert software for fast and easy part preparation, localized print strategies
Layer Thickness
10 - 100 micrometers. Smallest feature size: x=100 µm, y=100 µm, z=20 µm
Build Volume
140 mm (L) x 140 mm (W) x 100 mm (H)
Material
Ni625 - known for its combination of high strength and excellent corrosion resistance. LaserForm Ni625 (B) is the ideal material for industries where these two strengths need to come together: chemical, marine, aerospace and nuclear industry. Applications include: reaction vessels, tubing, heat exchangers, valves, engine exhaust systems, turbine seals, propeller blades, submarine fittings, propulsion motors, reactor core and control-rod components in nuclear water reactors.
